當前位置：主頁>產品列表>Mixing & Blending>雙螺旋錐形混合機（CE）

雙螺旋錐形混合機（CE）
Double Screw Conical Mixer (CE Approved)

1. 概述( Description )：
雙螺旋錐形混合機在化工、醫藥、食品、建材等領域廣泛使用，可用于粉體與粉體的混合、粉體添加少量液體混合、粉體與顆粒的混合等工藝。

每批次處理能力1~20立方米
每批次處理物料0.5~15噸
所用混合時間在15~30分鐘
設備材質可為316L、321、304、碳鋼

Horizontal ribbon mixing machine is widely used in the chemical industry, medicine, food, building materials and other fields ,It can be used for powder and powder mixture, the powder to add a small amount of liquid mixing, powder and particle mixing process.

Each batch processing capacity of 1 to 20 cubic meters
0.5 to 15 tons of material per batch
Mixing time is between 15 and 30 minutes
Equipment material can be 316L, 321,304, carbon steel

2. 原理(Principle)：

螺旋的公、自轉使物料在錐體內產生復合運動，主要產生四種運動形式：
The principle of this machine is the compound movements of the materials in the cone caused by the rotation and revolution of the screw.There are four type of movements:

2.1. 螺旋沿壁公轉，使物料沿錐壁作圓周運動；
The revolution of the screw along the inner wall causes the materials produce circumferential movement along the wall.

2.2. 螺旋自轉使物料自錐底沿螺旋上升；
The rotation of the screw causes the materials go up from the bottom of the screw spirally.

2.3. 螺旋的公、自轉復合運動使一部分物料被吸收到螺旋圓柱面內同時受螺旋自轉的離心力作用使螺旋圓柱面內的一部分物料向錐外體徑向排放；
The rotation and revolution of the screw causes part of the materials absorbed to the cylindroid of the screw.Meanwhile under the action of the centrifugal force, part of the materials in the screw cylindroid are discharged radially.

2.4. 上升的物料受自身重力作用下降。四種運動在混合機內產生對流、剪切 、擴散、從而達到快速均勻混合的目的。
The materials gong up drops under the action of the gravity.These four types of movements causes the materials convection,shearing and diffusion inside the cone.Thus quick and uniform mixing can be achieved.

3. 應用范圍(Scope of application)：

本機適用于醫藥、化工、食品、冶金、建材等行業的粉狀、粒狀物料的混合以及均質化。
This machine is suitable for pharmaceutical, chemical, food, metallurgy, building materials and other industries powder, granular material mixing and homogenization.

4、技術參數Technical parameter
