當前位置：主頁>產品列表>粉碎研磨設備>不銹鋼重錘式破碎機（CE）

不銹鋼重錘式破碎機（CE）
Heavy Hammer Mill ( Made of Stainless Steel ) ( CE Approved )

1. 概述( Description )：

不銹鋼重錘式粉碎機廣泛應用于制藥工業，食品工業，化學，橡膠，電子工業等領域。

2. 原理( Principle )：

塊狀物料從粉碎機頂部均勻的加入，經過一個自關閉式門后，進入高速旋轉的重錘粉碎區，重錘下面有篩網，網的孔徑可選，小于孔徑的物料穿過網孔排出粉碎機外，大于孔徑的物料繼續在內部被粉碎。當重錘高速旋轉的時候，會產生正壓，有氣流產生，若用于固體粉碎，可能會產生粉塵，一個額外的除塵器需要安裝在粗碎機的旁邊，用來收集從粗碎機出來的粉塵。
Big briquettes being feed into the mill from the top inlet , there is a self-close door for protect material coming out once briquettes come in ,briquettes come into the high speed hammer area , a net under the hammer , the net hole size is selectable , material being crushed by high speed rotating hammer , the crushed material which size less than net hole can come out , other big briquettes was continuously crushed by rotating heavy hammer. ?when hammer rotating , some pressure and air flow generated ,if for crush solid material without moisture , one additional filter beside the mill for collect the dust from the outlet of mill is necessary .

3、應用范圍（ Application Scope ）

適用于需要將原料破碎成顆粒，篩網的孔徑一般在10 -35mm 。
It is suitable for the raw materials that need to be crushed into granules , the net size normally in10 to 20 mm

4、技術參數Technical parameter

Note: customized equipment is acceptable for us .
CE & UL requirement is acceptable for us .
