當前位置：主頁>產品列表>混合攪拌設備>自動提升料斗混合機(方錐混合機)（CE）

自動提升料斗混合機(方錐混合機)（CE）
Automatic lifting hopper mixer ( Square Conical Mixer ) (CE Approved)

1. 概述( Description )：
自動提升料斗混合機能自動完成提升、夾持、混合、下降等全部動作。配一臺自動提升料斗混合機及多個不同規格的混合料斗,就能滿足大批量、多品種的混合要求，是藥廠總混的理想設備。同時在制藥、化工、食品等行業廣泛使用。

Automatic lifting hopper mixer can automatically complete the lifting, clamping, mixing, move down actions . With an automatic lifting hopper mixer and a number of different mixing hopper, will be able to meet the large quantities, more varieties of mixed requirements,it is the ideal mixture of pharmaceutical industry ,It also widely used in the pharmaceutical, chemical, food and other industries .

2. 特點(Features)：

本機的主要特點是:
1、使用PLC與變頻調速使整機實現程序控制，采用方錐形料斗繞著對稱軸旋轉運動，物料在料斗中產生不對稱、多方向、多維運動，回轉體(混合料斗)與回轉軸線成30°夾角，混合料斗中的物料隨回轉體翻動外，同時沿斗壁做切向運動，產生強烈的翻轉和高速的切向運動，從而達到******的混合效果。。
Use PLC and frequency inverter to achieve the program control, with a smooth transmission, reliable structure, large amount of mixing, use square cone hopper rotary around the Symmetry axis ,the material in the hopper with asymmetric, multi- Movement, the rotor (mixing hopper) and the rotary axis at an angle of 30 °, the material in the mixing hopper turing with the rotating body, and material do tangential movement on the container wall, resulting in a strong flip and high-speed tangential movement, so as to achieve The best mixing effect.

2、設置紅外線安全裝置及防誤操作裝置的出料蝶閥，確保生產安全。物料可在同一容器中通過不同的工序段，不需要頻繁地轉料、加料等程序。有效地控制粉塵與交叉污染，減少物料的損失，控制物料的分層，優化了生產工藝，完全符合藥品生產的GMP要求。
Set the infrared safety device and anti-misoperation device out of the butterfly valve to ensure production safety. Materials can be in the same container through a different block, do not need frequent transfer, feeding and other procedures. Effectively control dust and cross pollution, reduce material loss, control material stratification, optimize the production process, fully meet the GMP requirements of pharmaceutical production
3, with big storage capacity for the parameter, can store 20 different materials (or the same kind of material at different stages of production) process parameters, you can call different process directly .
3、參數儲存量大，可儲存20組不同物料（或同種物料不同生產階段）的工藝參數，使用時直接調用即可。
4、采用了性能穩定、可靠的紅外線光電傳感器作為本機的安全防護裝置之一，有效地保障了設備工作時的人員安全。
use stable performance, reliable infrared photoelectric sensor as one of the local safety protection device, effectively protect the staff safety when he operate the equipment .

4、技術參數Technical parameter
