當前位置：主頁>產品列表>干燥蒸發設備>振動流化床干燥機（CE）

振動流化床干燥機（CE）
Vibrating Fluidized Bed Drying Equipment (CE Approved)

1.原理Principles

物料自進料口進入機內，在振動力的作用下，物料沿水平方向拋擲向前連續運動，熱風向上穿過流化床和濕物料換熱，濕空氣經旋風分離器除塵后由排風口排出，干燥物料由排料口排出。

Raw material is fed into the machine from the inlet and moves forward continuously along the level of fluidized-bed under the action of vibration. The hot air passes through fluidized-bed and carries out heat exchange with humid raw material. Then the damp air is exhausted out through cyclone separator and dust extractor and the dry raw material is discharged through discharge outlet.

2.應用范圍Scope of application

◆醫藥化工：各種壓片顆粒，硼酸、硼砂、苯二酚、蘋果酸、馬來酸等。

◆食品建材：酒糟、味精、砂糖、食鹽、礦渣、豆瓣、種籽等。

◆還可用于物料的冷卻、增濕等。

◆ Pharmaceutical and chemical industries: all kinds of press tablet and granule, boric acid, borax, dihydroxybenzene,malicacid, maleic acid and so on;

◆ Foodstuff and construction material industries: less,monosodium glutamate, edible sugar, edible salt, mine residue,Bean, seeds and so on;

◆ It can also be used for raw materials to add damp or cooling and so on.

3.特點Featurs

◆物料受料均勻，熱交換充分，干燥強度高，比普通干燥機節能 30 ％左右。

◆振動源采用振動電機驅動，運轉平穩、維修方便、噪音低、壽命長。

◆流態化穩定，無死角和吹穿現象。

◆可調性好，適應面寬。

◆對物料表面損傷小，可用于易碎物料的干燥，物料顆粒不規則時亦不影響工作效果。

◆采用全封閉式的結構，有效地防止了物料與空氣的交叉污染，作業環境清潔。

◆ Raw material is heated evenly and heat exchange is fully and dry capacity is high. Compared with ordinary dryer, the energy can be saved about 30%.

◆ The vibration is created by motor. It is stable in operation and convenient in maintenance, with low noise and long life;

◆ The fluidized state is stable and no dead angle and phenomenon of being broken out;

◆ It is good in adjustment and wide in application.

◆ There is little damage to the surface of raw materials. The equipment can be used for drying raw materials that are easily broken. The drying effect will not be affect ed even if raw materials are anomalous shaped; It can efficiently prevent the cross pollution between raw material and air because the equipment adapts fully closed structure. The environment of operation is clean.

4.技術參數Technical parameter

?
